Code:
////////////////////////////////////////////////////////////////////////////////

// LoopRez v0.6, by Ged Larsen, 20 December 2006

//

// - rez a number of objects in an ellipse, whose size is determined by xRadius and yRadius

// - all facing "outwards", along a tangent to the ellipse

// - can set how much the objects flare outwards

// - properly handles object rotation corrections (for example, X-axis 180 degree rotation helps for flexi-prim skirts)

// - can also get a 'saddle' bend, to generate a bend that might help for necklaces (from Ariane Brodie)

//

// To use:

// 1) create a prim that will contain this script and the object to use

// 2) put the script into the prim

// 3) create an object that will be used, and name it "Object"

// 4) put "Object" into the prim containing the script, by dragging it from your inventory

// 5) get out of Edit Mode, and touch the prim

//

// Random note:

// - this version does NOT insure equal spacing of objects along the perimeter of the ellipse

// - i.e., objects "bunch up" at the long ends of an ellipse; the effect should be acceptable for non-extreme ellipses

// - even spacing of objects can be accomplished, but requires simulation of integral calculus, which slows down the script

//

// References:

// - tangent formulas from: http://mathworld.wolfram.com/Ellipse.html





////////////////////////////////////////////////////////////////////////////////

// CONFIGURATION PARAMETERS, change these to your liking



string objectName = "Object"; // object to use; will need to be in the inventory of the prim containing this script

integer numObjects = 34; // how many objects

float xRadius = 0.2; // ellipse x-axis radius in meters

float yRadius = 0.25; // ellipse y-axis radius in meters

float flareAngle = 0.0; // how many DEGREES the bottom of object will flare outwards, the "poof" factor

float bendCoefficient = 0.0; // makes a "saddle shape", bends DOWN this number of meters at extremes of X-axis

vector rotOffset = <0.0, 0.0, 270.0>; // rotation offset in DEGREES -- fixes the rotation of ALL objects; for flexi prims, often you will want <180.0,>

vector posOffset = <0.0, 0.0, 2.0>; // position offset







////////////////////////////////////////////////////////////////////////////////

// No need to mess with anything below here



makeLoop()

{

integer n; // which object is being placed

float theta; // angle in radians

vector pos; // position

rotation rot; // rotation in quaternion format



for(n = 0; n < numObjects; n++) {



theta = TWO_PI * ( (float)n / (float)numObjects );



pos.x = xRadius * llCos(theta); // ellipse: 2x xRadius meters wide

pos.y = yRadius * llSin(theta); // ellipse: 2x yRadius meters wide

pos.z = -bendCoefficient*llCos(theta)*llCos(theta); // saddle shape, bending downwards on X-axis

pos = pos + llGetPos() + posOffset;



rot = llEuler2Rot(<rotOffset.x*DEG_TO_RAD, rotOffset.y*DEG_TO_RAD, rotOffset.z*DEG_TO_RAD>); // user-chosen rotation offset correction

rot = rot * llEuler2Rot(<0, -1*flareAngle*DEG_TO_RAD, 0>); // flare generation (poof)



// the following make the objects face outwards properly for an ellipse; using theta alone is only correct for a circle

// the scary formula calculates a unit vector TANGENTIAL to the ellipse, and llRotBetween is used to figure out how much the object needs to rotate to lie parallel to the tangent

rot = rot * llRotBetween(<0.0,1.0,0.0>, <-1.0 * xRadius * llSin(theta) / ( llSqrt ( (yRadius*yRadius * llCos(theta) * llCos(theta)) + (xRadius*xRadius * llSin(theta) * llSin(theta))) ),yRadius * llCos(theta) / ( llSqrt ( (yRadius*yRadius * llCos(theta) * llCos(theta)) + (xRadius*xRadius * llSin(theta) * llSin(theta))) ),0.0>);

if ( n== (numObjects/2) ) // LSL's implementation of llRotBetween at theta = pi radians is reversed at 180 degrees, so this manually corrects it

rot = rot * llEuler2Rot( <0,PI,0> );



llRezObject(objectName, pos, ZERO_VECTOR, rot, 0);

}

}



default

{

touch_start(integer total_number)

{

if (llDetectedOwner(0) == llGetOwner())

{

makeLoop();

}

}

}
